instrument cluster swap?
08-18-2003
#1
Registered!!
Thread Starter
Join Date: Oct 2001
Location: Oklahoma, US
Posts: 709
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 0
instrument cluster swap? I don't know if this is the right forum or not or if this has been asked before, I tried to search and couldn't find what I wanted, so sorry if its a repost. I have a friend who just bought a 2k3 civic coupe and I love the look of the dash/guages and all now. It is really smooth looking! I have a 2k1 EX Coupe and I wanted to know if it would be possible to swap out the instrument cluster and if so how hard would it be and what would I need to know or do in order for it to work? Thanks!
08-18-2003
#3
Registered!!
iTrader: (10)
Join Date: Oct 2002
Location: NJ
Age: 40
Posts: 4,767
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 310 did you really try to search?
guamcivic's correct. IT IS POSSIBLE, but only to an electrical genious who works for Honda. The harnesses in '01 and '02 Civics aren't "plug&play" with the sockets on the 03 gauge clusters.
But since you wanted to know... First you'd have to learn how the cluster harnesses are set up for the '03 (i.e. You have to seperate the wires in the cable and find out what each wire stands for). Then you have to find out how the wiring in the cluster harnesses of the '01 are set up also. Now that you know the wires of the '01, you have to separate those and match the way '03 wires are set up. You'd have to find harness plugs that will fit an '03 cluster to put on your rearranged '01 cables of wires, so they will plug in an '03 cluster.
It sounds pretty long and tedious, and it is. Unless you have all the right information in front of you. The hardest thing is probably trying to separate all the wires and match them accordingly.
On ebay, there used to be 'chrome bezel rings' that are sold for our instrument clusters. But very rarely are they sold any more.
guamcivic's correct. IT IS POSSIBLE, but only to an electrical genious who works for Honda. The harnesses in '01 and '02 Civics aren't "plug&play" with the sockets on the 03 gauge clusters.
But since you wanted to know... First you'd have to learn how the cluster harnesses are set up for the '03 (i.e. You have to seperate the wires in the cable and find out what each wire stands for). Then you have to find out how the wiring in the cluster harnesses of the '01 are set up also. Now that you know the wires of the '01, you have to separate those and match the way '03 wires are set up. You'd have to find harness plugs that will fit an '03 cluster to put on your rearranged '01 cables of wires, so they will plug in an '03 cluster.
It sounds pretty long and tedious, and it is. Unless you have all the right information in front of you. The hardest thing is probably trying to separate all the wires and match them accordingly.
On ebay, there used to be 'chrome bezel rings' that are sold for our instrument clusters. But very rarely are they sold any more.
Last edited by XxSoVeReiGNxX; 08-18-2003 at 07:45 AM.
08-18-2003
#6
Registered!!
Thread Starter
Join Date: Oct 2001
Location: Oklahoma, US
Posts: 709
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 0 I have an idea of what harnesses are and all, I basically wanted to know if it was a simple plug and play job or if it would require rewiring. I could do the work, but basically it sounds like its not worth it. I did try to search and I really didn't find what I was looking for, sorry. Thanks for the responses.
08-18-2003
#8
Registered!!
Join Date: Jul 2003
Location: Fontana, CA
Age: 45
Posts: 3,200
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 0 lol I'm workin on those harnesses now I'll let everyone know what happens!!! I havent had as much free time as I'd like so it will take a little while. 2002 EX to 2003 EX!
08-18-2003
#9
Registered!!
Thread Starter
Join Date: Oct 2001
Location: Oklahoma, US
Posts: 709
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 0 see, thats what I wanted a 2001 EX to a 2k3 EX for a coupe, I don't know though, seems like the trouble isn't really worth it. Also wouldn't you end up with a reset odometer?
08-18-2003
#11
Registered!!
iTrader: (10)
Join Date: Oct 2002
Location: NJ
Age: 40
Posts: 4,767
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 310 celica please keep us informed. I really would like to have an '03 cluster, just for the chrome and red rings around each pod. But I have a DX, and the only thing I'm concerned with right now is a tachometer. I'm just waiting for my car to match miles with an '02 cluster I have on stand by.
08-18-2003
#14
Search and Learn
iTrader: (34)
Join Date: May 2002
Location: 909, Socal
Posts: 14,004
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 408 Originally posted by Green Civic
Would that be the same for a 2001 ex to a 2002 rsx-s? A wiring problem? Or is it plug and play? Thanx.
Would that be the same for a 2001 ex to a 2002 rsx-s? A wiring problem? Or is it plug and play? Thanx.
08-18-2003
#15
Registered!!
iTrader: (10)
Join Date: Oct 2002
Location: NJ
Age: 40
Posts: 4,767
Likes: 0
Received 0 Likes
on
0 Posts
Rep Power: 310 green... that would be lots harder. It wouldn't be plug & play because the rsx is a differently designed car. For one thing, the redlines are different.
I'm not sure but I think the 2002 si cluster has greater "swap-ability" with an rsx cluster, being that they share almost identical engines.
I'm not sure but I think the 2002 si cluster has greater "swap-ability" with an rsx cluster, being that they share almost identical engines.
